Pure Sine Wave Inverter 12V 24V 48V Solar Inverter 1KW 2KW 3KW 4KW 5KW 6KW Low Frequency Hybrid Solar Inverter Factory
Output Type: Single
Inverter Efficiency: 85%
MPPT Efficiency: 99%
Place of Origin: Guangdong, China
Model Number: YK-G02
Brand Name: YingKe
Input Voltage: 12VDC/24VDC/48VDC
Output Voltage: 110VAC/220VAC; ±3%
Output Current: 5A-30A Adjustable (P2)
Output Frequency: 45-65Hz
Type: DC/AC Inverters
Product name: Solar Hybrid Inverter
Application: Solar Power System Home
Inverter type: Off-grid Power Inverter
Battery type: Lead Acid/GEL/AGM/LiFePO4
Display: LCD Display
Keyword: Solar Energy Power Inverter
Efficiency: >85% (80% Resistive Load)
Feature: Hybrid Solar Inverter Charger
Frequency: 45-65Hz
OEM/ODM: Accepted
Products Description
Global Professional Solar Charge Controller Factory, Providing OEM & ODM Solar Charge Controller Solution Services.
Description
Solar Power Off Grid Hybrid Inverter with MPPT Charge Controllers Features:
1. Dual CPU itelligent control technology, high performance.
2. Pure sine wave AC output, can adapt to various types of load.
3. Mains mode l energy saving mode l battery mode can be chose.
4. Charing current l battery type can be set, more convenient to use.
5. LCD module displays the operating parameters of theequipment in real time.
6. Inelligent fan control, safe and rebiable.
7. Built-in MPPT solar controller, overcharge and overdischargeprotection, current limiting charge, multiple protection.
8. Output overload, short circuit protection, a variety of automaticprotection and alarm reminder.
| Technical Parameter | ||||||||||
| Model No. | MB-702 | MB-1002 | MB-1202 | MB-1502 | MB-2002 | MB-3002 | MB-4002 | MB-5002 | MB-6002 | MB-7002 |
| Rated Power | 700W | 1KW | 1.2KW | 1.5KW | 2KW | 3KW | 4KW | 5KW | 6KW | 7KW |
| Battery | ||||||||||
| Rated Voltage | 12VDC/24VDC/48VDC/96VDC | |||||||||
| Charge Current | 5A-30A(Adjustable) | |||||||||
| Battery Type | Lead-acid, GEL, LiFeP04 | |||||||||
| Input | ||||||||||
| Voltage Range | 170-275VAC | |||||||||
| Frequency | 45-65Hz | |||||||||
| Output | ||||||||||
| Voltage Range | 110VAC±10%/120VAC±10%/220VAC±10%/230VAC±10%/240VAC±10% | |||||||||
| Frequency | 50/60Hz ±1% ( Inverter Mode) | |||||||||
| Output Wave | Pure Sine Wave | |||||||||
| Convertion Time | <7mS (Typical Load) | |||||||||
| Efficiency | >85% | |||||||||
| Protection Function | Battery Overvoltage Protection, Battery Undervoltage Protection, Overload Portection, Short Circuit Protection, Overtemperature Protection etc. | |||||||||
| Solar Charge Controller (optional) | ||||||||||
| Input Voltage | MPPT: 18VDC~180VDC | |||||||||
| PV Power | 12VDC-60A (800W), 24VDC-60A(1600W), 48VDC-60A(3200W) | |||||||||
| PV charge current | 40A / 60A | |||||||||
| Efficiency | >99% | |||||||||
| Voltage of Boosting Charge | 12/14.2VDC; 24V/28.4VDC; 48V/56.8VDC | |||||||||
| Voltage of Floating Charge | 12/13.75VDC; 24V/27.5VDC; 48V/55VDC | |||||||||
| Physical Parameter | ||||||||||
| Operation Temperature | -0 – +40℃ | |||||||||
| Storage Ambient Temperature | -15 – +50℃ | |||||||||
| Operation/Storage ambient | 10-90% No Condensation | |||||||||
| Gross Weight (kg) | 10 | 12 | 14 | 16 | 20 | 25 | 30 | 32 | 36 | 40 |
| Product Size: D*W*H (mm) | 370*310*150 | 485*350*170 | ||||||||
| Package Size: D*W*H (mm) | 445*385*245 | 620*425*262 | ||||||||
| Products Specification are subjected to chang. | ||||||||||
Our Factory’s Advantages
13 Years of experience in the Solar Charge Controller manufacturing industry, providing customers with professional customized processing solutions.
Yingke Intelligent Electronic Technology Co., Ltd. is a professional supplier with 13 years of experience in producing solar controllers, inverters, and other solar products. We offer a wide range of solar controllers and inverters for residential, educational, and commercial use.Our solar products have obtained CE, RoHS, and FCC international certifications to ensure strict quality control and reliability. We specialize in providing OEM and ODM services to meet specific customer needs.
Providing OEM & ODM Solution Services
Global Professional Solar Charge Controller Factory, Providing OEM & ODM Solar Charge Controller Solution Services.
NO.1 Factory Production Advantages
12,000 square meters factory area, 15 subdivided production lines. Meet the requirements of inverter shape design, special power and voltage customization. Designated partners of more than 150 well-known brand enterprises, help their profits increase by up to 35%.
NO.2 Professional Engineering Team
An engineering team composed of 15 engineering R&D personnel, each of whom has been engaged in the renewable energy or power supply industry over 10 years. Various customization requirements of inverter, the engineering team will provide a feasible plan report within 24 hours.
NO.3 Continuous Innovation And Development
Focusing on the field of renewable energy and power industry, it provides optimization and replacement services for inverters and solar power solutions, and has obtained up to 30 national patents so far.
NO.4 Sincere Cooperation For Mutual Benefit
Hybrid solar power inverter customer service covers more than 100 countries and regions in the world, ensuring worry-free after-sales. Professional after-sales service team, timely resolution of customer issues!
